Steering Assembly

No.

Name/Description

Part Code

01

Tyre

D500 001

02

Inner Tube

D500 002

03

Wheel

D500 003

05

Hub Drum (Rear)

D500 005

06

Rear Axle Bearing

D500 006

11

Brake Backplate

D500 011

12

Brake Shoes

D500 012

13

Brake Springs

D500 013

14

Brake Camshaft

D500 014

15

Brake Lever

D500 015

22

Suspension Bush

D500 022

25

Pivot Bolt

D500 025

26

Pivot Bolt Lock Nut

D500 026

30

Nut

D500 030

37

Nut

D500 037

40

Suspension Unit (rear)

D500 040

43

Washer

D500 043

51

Rear Y Frame & Chain Guard

D500 051

52

Attachment Brackets

D500 052

54

Rear Axle

D500 054

56

Rear Axle Centre Spacer

D500 056

57

Rear Hub Spacer

D500 057

59

Sprocket

D500 059

60

Adapter

D500 060

61

Lock Ring

D500 061

62

Drive Chain

D500 062

63

Split Link

D500 063

64

Chain Tensioner

D500 064

65

Chain Cover

D500 065

67

Chain Cover Spacer

D500 067
