Front Axle Assembly

No.

Name/Description

Part Code

01

Tyre/Tire

D500 001

02

Inner Tube

D500 002

03

Wheel

D500 003

04

Front Brake Drum

D500 004

05

….

D500 005

06

Hub Bearings

D500 006

07

Hub Spacer

D500 007

08

Hub Cap

D500 008

09

…

D500 009

10

…

D500 010

11

…

D500 011

12

Brake Shoes

D500 012

13

Brake Shoe Spring

D500 013

14

Brake Camshaft

D500 014

15

Brake Lever

D500 015

16

Stub Axle Right Hand

D500 016

17

Stub Axle Left Hand

D500 017

17a

Stub Axle (only)

D500 017a

18

Stub Axle Nut

D500 018

19

Spacing Washer

D500 019

20

King Pin

D500 020

21

King Pin Locknut

D500 021

22

Bushes

D500 022

23

A Arm Right Hand

D500 023

24

A Arm Left Hand

D500 024

25

Pivot Bolt

D500 025

26

Pivot Bolt Lock Nut

D500 026

27

A Arm Front Mounting (Bracket)

D500 027

28

A Arm Rear Mouting (Bracket)

D500 028

29

Bracket Mounting Bolt

D500 029

30

Bracket Mounting Nuts

D500 030

31

Track Rod Left Hand

D500 031

32

Track Rod Right Hand

D500 032

33

Track Rod Lock Nut

D500 033

34

Ball Joint

D500 034

35

Ball Joint Bolt

D500 035

36

Ball Joint Spacer

D500 036

37

Ball Joint Nut

D500 037

38

….

D500 038

39

Suspension Unit (Front)

D500 039

40

…

D500 040

41

Suspension Unit Bolt

D500 041

42

Suspension Unit Attachment Bracket

D500 042

43

Washer

D500 043
